Automatic Cold Room Price 3ton 5ton 10ton Walk in Freezer Blast Freezer Room
Cooling room for fruit, vegetable, and dairy products storage, with middle temperature, custom for your special need, 50~200 mm PU/PIR panel with good insulation, equipped with a high-efficiency condensing unit, power consumption saving cost.
Dimension: | Customized |
Temperature: | -45~+30°C degree, can be customized |
Panel thickness: | 75mm,100mm,120mm,150mm,180mm,200mm optional |
Steel cover: | Color steel plates and embossed aluminum plates |
Type of door: | Hinge door, Sliding door, Swing door |
Refrigeration unit: | Box-type unit, Semi-hermetic unit and customization |
Refrigeration type: | Custom Air cooled/water cooled/evaporation cooled |
Refrigeration: | Custom R22, R404a, R447a, R507a refrigerant |
Voltage: | 220V, 380V, 440V optional |
Industry: | Fruit/meat/vegetable, plants/flowers, Chemical factory/medicine etc. |
Categories
New Products
Product Detail
Features
✅ Keep your vegetables/ fruits fresh for long-term!
✅ Best insulation panels to save the operation cost!
✅ Design best solution suited to your storage requirements!
✅ Best brand color plate material to be used for many years!
✅ High efficiency refrigeration unit to meet your operation need!
2.Storage product:
Vegetables/Fruits/Milk/Yoghourt/Flower, Etc…
3. Panels surface suggestion:
(1) Color plate steel
(2) Stainless steel
(3) Other chooses: salinization/ aluminum/ galvanized
Color plate steel is the best choice for vegetables/ fruits storage: anti-rust, good insulation, cost-effective, long life span.
Cold Storage Facility Solutions
Food Cold Storage
Food cold storage is a specialized technique that uses cold room refrigeration units to decrease the temperature of food and maintain it at a low temperature to prevent spoilage, extend the shelf life, and preserve the quality of food.
Meat Freezer Room
Meat cool room is using cold room refrigeration system to decrease the temperature of meat. If meat products are not stored or preserved within the right temperature, the quality will get contaminated.
Fruit and Vegetable Storage
Fruit cold rooms and vegetable cold storage rooms are essential components of the food industry, aiding in the preservation and maintenance of the quality and freshness of fruits and vegetables.
Seafood Freezer Room
Seafood needs to be stored in a suitable environment to keep their nutritious values intact. A seafood cold room equipment offers substantial economic benefits by extending product shelf life, enabling market expansion, and reducing waste.
Application of Cold Storage Rooms
10°C-15C Cold Room: can be used in processing workshop, temperature control hall, receiving and delivery area, function room, etc.
0°C-10°C Cold Room: can be used for meat pre-cooling, meat deacidification, fruit and vegetable preservation, low temperature passage, medicine storage, etc.
-15°C~-30°C Cold Room: can be used for low temperature storage, cold chain logistics, etc.
-30°C~-40°C Cold Room: can be used for food quick-freezing,tunnel freezer, etc.
-50°C~-80°C Cold Room: can be used for tuna storage, vaccine storage, etc.
1. Panels
(1) Panels thickness: 50, 75, 100, 120, 150, 180, 200mm.
(2) Panels density: 42kg/m3
Density calculation test:
Width=0.2m
Length=0.25m
Height=0.12m
Weight=0.252kg
Density=Weight/Volume=0.252/(0.2×0.25×0.12)
=42kg/m3
(3) Cam lock: Galvanized, easy and convenient for installation.
(4) Fireproofing
Fireproofing grade: A>B1>B2>B3 (Gradually increase from right to left)
Our PU panels: B1steel+B2foaming=B1 PU panels
(5) Surface materials
2. Doors:
(1) Hinged door:
√ Designed: by Teledoor in Germany.
√ Surface materials: 0.6mm color plate.
√ Door hinges German STUV, EU standard.
√ Door’s hardware, switches and door seal: best quality.
√ Our door can be used 2-3 times longer than other suppliers’.
(2) Sliding doors:
√ Guide cover: protect guide from dust and deformation.
√ Professional design: no pressure on wall panel and cam lock.
√ Strong aluminum frame system: support the door, lead the door weight to floor.
(3)Self-closing doors:
√ Designed: self-closing hinge
√ Function: automatically shut off
√ Application: restaurant, hotel, etc…
When you are often too busy to close the door, the self-closing door is a good choice.
√ The feature of our monoblock unit:
Installation is easy.
Defrosting by hot gas, eco-Friendly
Automatic defrosting water evaporation system
Hermetic compressor, quiet and high efficiency
Multifunctional digital control
Pre-charged with refrigerant
Main Components of Cold Storage Room
